Brand: HiLetgo | Weight: 0.2 ounces | Dimensions: 0.25 x 0.25 x 0.26 inches
Key Features
- Type:Accessories,
- Accessories Function:Motor,
- Model:LDTR-417995,
- Dimension(cm):7*5*2,
- Net Weight(kg):0.006,
Product Description
Main chip: NE 555;
Input Voltage: 5 V – 15 VDC.
When power supply is 5 V, the output current can be 15 MA around;
When 12V power supply, the output current can 35MA around;
Input current:> = 100 MA
Output amplitude: 4.2 V V – PP to 11.4 V V – PP. (Different input voltage, the output amplitude will be different)
Output with LED indication (low level, LED will on (Maximum output current:> = 15 MA (when 5 V power supply, V-PP greater than 50%),> = 35 MA ;
High level, LED will off; low frequency, the LED flashes);
Size: Approx.3.1 * 2.4 cm / 1.22 * 0.94 inch;
Package Included:
5 x HiLetgo NE555 5 V – 15 VDC Frequency Duty Cycle Adjustable Module Square Wave Signal Generator
Product Images
